TL602和ML602型号是Connor-Winfield最新推出的温补晶振
Connor-Winfield宣布推出符合ITU-T G.8262的新TCXO6G晶振,TL602-010.0M,伊利诺伊州奥罗拉–TL602和ML602是温度补偿晶体振荡器（TCXO晶振）石英晶振型号，专门设计用于与0.1Hz配合使用（更高）滤波器带宽，符合基于T1的层次结构规范如ITU-TG.8262选项1和2ECC以及ITU-TG.813选项1和2SEC，用于Sonet、IEEE1588和同步以太网的第3层。ConnorWinfield晶振的TCXO生产线利用模拟温度补偿，具有出色的短期稳定性特性。TL602和ML602这两款TCXO在工业温度范围为-40至+85℃。它们也是小型的出色频率产品的参考选择例如蜂窝网络、无线应用设备和仪器仪表应用。
Connor-Winfield announces new ITU-T G.8262 compliant TCXO6G crystal oscillator,TL602-010.0M, Aurora, IL - TL602 and ML602 are temperature compensated crystal oscillator (TCXO crystal oscillator) crystal oscillator models. Specifically designed for use with 0.1Hz (higher) filter bandwidth-compliant with T1-based hierarchy specifications such as ITU-TG.8262 Options 1 and 2ECC and ITU-TG.813 Options 1 and 2SEC for Sonet, IEEE1588 and Layer 3 of Synchronous Ethernet. ConnorWinfield's TCXO line utilizes simulated temperature compensation for excellent short-term stability. The two TCXOs, TL602 and ML602, have an industrial temperature range of -40 to +85 ° C. They are also the reference choice for small, excellent frequency products such as cellular networks, wireless applications, and instrumentation applications.
特征：可用频率为10MHz、12.8MHz、19.2MHz、19.44MHz、20MHz和24.576MHz。LVCMOS或削波正弦波，固定输出或电压控制，符合在.1Hz带宽下测量的MTIE和TDEV模板在整个工业温度范围内具有280ppb峰峰值温度稳定性。在12kHz-20MHz频段内低于300ps的抖动性能，使用精度为±4.6ppm，完全符合ROHS和REACH标准，7x5毫米（TL602）或5x3.2毫米（ML602）SMD晶振封装选项。
Features: Available frequencies are 10MHz, 12.8MHz, 19.2MHz, 19.44MHz, 20MHz and 24.576MHz. LVCMOS or clipped sine wave, fixed output or voltage control, conforming to the MTIE and TDEV templates measured at a bandwidth of.1Hz with 280ppb peaking temperature stability over the entire industrial temperature range. Jitter performance below 300ps in the 12kHz-20MHz band, accuracy of ±4.6ppm in use, full ROHS and REACH compliance, 7x5 mm (TL602) or 5x3.2 mm (ML602) package options.
| 编码 | 生产商 | 型号 | 类型 | 频率 | 输出 | 电压 |
| CWX823-012.0M | Connor Winfield | CWX823 | XO (Standard) | 12 MHz | LVCMOS | 3.3V |
| CWX823-050.0M | Connor Winfield | CWX823 | XO (Standard) | 50 MHz | LVCMOS | 3.3V |
| CWX823-033.0M | Connor Winfield | CWX823 | XO (Standard) | 33 MHz | LVCMOS | 3.3V |
| CWX823-012.288M | Connor Winfield | CWX823 | XO (Standard) | 12.288 MHz | LVCMOS | 3.3V |
| CWX813-040.0M | Connor Winfield | CWX813 | XO (Standard) | 40 MHz | LVCMOS | 3.3V |
| CWX813-025.0M | Connor Winfield | CWX813 | XO (Standard) | 25 MHz | LVCMOS | 3.3V |
| CWX813-010.0M | Connor Winfield | CWX813 | XO (Standard) | 10 MHz | LVCMOS | 3.3V |
| CWX813-024.576M | Connor Winfield | CWX813 | XO (Standard) | 24.576 MHz | LVCMOS | 3.3V |
| CWX813-050.0M | Connor Winfield | CWX813 | XO (Standard) | 50 MHz | LVCMOS | 3.3V |
| CWX823-125.0M | Connor Winfield | CWX823 | XO (Standard) | 125 MHz | LVCMOS | 3.3V |
| CWX813-100.0M | Connor Winfield | CWX813 | XO (Standard) | 100 MHz | LVCMOS | 3.3V |
| CWX813-080.0M | Connor Winfield | CWX813 | XO (Standard) | 80 MHz | LVCMOS | 3.3V |
| D32G-016.368M | Connor Winfield | D32G | TCXO | 16.368 MHz | Clipped Sine Wave | 3.3V |
| PB223-156.25M | Connor Winfield | PB | XO (Standard) | 156.25 MHz | LVPECL | 3.3V |
| TJ5F-050.0M | Connor Winfield | TJ5F | TCXO | 50 MHz | LVCMOS | 3.3V |
| TJ5F-040.0M | Connor Winfield | TJ5F | TCXO | 40 MHz | LVCMOS | 3.3V |
| TVJ6F-010.0M | Connor Winfield | DV75D | TCXO | 10 MHz | LVCMOS | 3.3V |
| TVJ6F-020.0M | Connor Winfield | DV75D | TCXO | 20 MHz | LVCMOS | 3.3V |
| TVJ6F-012.8M | Connor Winfield | DV75D | TCXO | 12.8 MHz | LVCMOS | 3.3V |
| D53G-020.0M | Connor Winfield | D53G | TCXO | 20 MHz | Clipped Sine Wave | 3.3V |
| TJ5E-025.0M | Connor Winfield | TJ5E | TCXO | 25 MHz | LVCMOS | 3.3V |
| TJ5E-027.0M | Connor Winfield | TJ5E | TCXO | 27 MHz | LVCMOS | 3.3V |
| P123-125.0M | Connor Winfield | P | XO (Standard) | 125 MHz | LVPECL | 3.3V |
| D75A-010.0M | Connor Winfield | D75A | TCXO | 10 MHz | LVCMOS | 3.3V |
| DV75C-010.0M | Connor Winfield | DV75C | TCXO | 10 MHz | LVCMOS | 3.3V |
| P223-100.0M | Connor Winfield | P | XO (Standard) | 100 MHz | LVPECL | 3.3V |
| TJ6F-020.0M | Connor Winfield | TJ6 | TCXO | 20 MHz | LVCMOS | 3.3V |
| P213-100.0M | Connor Winfield | P | XO (Standard) | 100 MHz | LVPECL | 3.3V |
| P213-156.25M | Connor Winfield | P | XO (Standard) | 156.25 MHz | LVPECL | 3.3V |
| T602-019.2M | Connor Winfield | T602 | TCXO | 19.2 MHz | LVCMOS | 3.3V |
| T602-030.72M | Connor Winfield | T602 | TCXO | 30.72 MHz | LVCMOS | 3.3V |
| T604-010.0M | Connor Winfield | T605 | VCTCXO | 10 MHz | LVCMOS | 3.3V |
| TB602-050.0M | Connor Winfield | TB | TCXO | 50 MHz | LVCMOS | 3.3V |
| T602-040.0M | Connor Winfield | T602 | TCXO | 40 MHz | LVCMOS | 3.3V |
| T604-040.0M | Connor Winfield | T605 | VCTCXO | 40 MHz | LVCMOS | 3.3V |
| M100V-020.0M | Connor Winfield | M100 | VCTCXO | 20 MHz | LVCMOS | 3.3V |
| M100V-010.0M | Connor Winfield | M100 | VCTCXO | 10 MHz | LVCMOS | 3.3V |
| M100F-020.0M | Connor Winfield | M100 | TCXO | 20 MHz | LVCMOS | 3.3V |
| DOT050F-010.0M | Connor Winfield | DOT050F | TCXO | 10 MHz | LVCMOS | 3.3V |
| DOCSC022F-030.72M | Connor Winfield | DOCSC | OCXO | 30.72 MHz | LVCMOS | 3.3V |
| DOCSC012F-025.0M | Connor Winfield | DOCSC | OCXO | 25 MHz | LVCMOS | 3.3V |
| OH100-61003CF-010.0M | Connor Winfield | OH100 | OCXO | 10 MHz | CMOS | 3.3V |
| OH100-61003CF-020.0M | Connor Winfield | OH100 | OCXO | 20 MHz | CMOS | 3.3V |
| OH300-61003CV-010.0M | Connor Winfield | OH300 | VCOCXO | 10 MHz | CMOS | 3.3V |
| OH300-50503CV-010.0M | Connor Winfield | OH300 | VCOCXO | 10 MHz | CMOS | 3.3V |
| OH300-50503CF-010.0M | Connor Winfield | OH300 | OCXO | 10 MHz | CMOS | 3.3V |
| OH300-50503CF-050.0M | Connor Winfield | OH300 | OCXO | 50 MHz | CMOS | 3.3V |
| OD100LP-81212SV-100.0M | Connor Winfield | OD100LP | VCOCXO | 100 MHz | Sine Wave | 12V |
| CWX823-024.0M | Connor Winfield | CWX823 | XO (Standard) | 24 MHz | LVCMOS | 3.3V |
| CWX823-008.0M | Connor Winfield | CWX823 | XO (Standard) | 8 MHz | LVCMOS | 3.3V |
| CWX823-027.0M | Connor Winfield | CWX823 | XO (Standard) | 27 MHz | LVCMOS | 3.3V |
| CWX813-012.288M | Connor Winfield | CWX813 | XO (Standard) | 12.288 MHz | LVCMOS | 3.3V |
| CWX813-024.0M | Connor Winfield | CWX813 | XO (Standard) | 24 MHz | LVCMOS | 3.3V |
| CWX823-100.0M | Connor Winfield | CWX823 | XO (Standard) | 100 MHz | LVCMOS | 3.3V |
| CWX823-064.0M | Connor Winfield | CWX823 | XO (Standard) | 64 MHz | LVCMOS | 3.3V |
| D32G-026.0M | Connor Winfield | D32G | TCXO | 26 MHz | Clipped Sine Wave | 3.3V |
| D32G-019.2M | Connor Winfield | D32G | TCXO | 19.2 MHz | Clipped Sine Wave | 3.3V |
| B31-038.4M | Connor Winfield | B31 | TCXO | 38.4 MHz | Clipped Sine Wave | 3.3V |
| B31-025.0M | Connor Winfield | B31 | TCXO | 25 MHz | Clipped Sine Wave | 3.3V |
| P122-125.0M | Connor Winfield | P | XO (Standard) | 125 MHz | LVPECL | 2.5V |
| LM113-200.0M | Connor Winfield | LM113 | XO (Standard) | 200 MHz | LVDS | 3.3V |
| VBLD861-100.0M | Connor Winfield | VBLD861 | VCXO | 100 MHz | LVCMOS | 3.3V |
| P212-156.25M | Connor Winfield | P | XO (Standard) | 156.25 MHz | LVPECL | 2.5V |
| T602-020.0M | Connor Winfield | T602 | TCXO | 20 MHz | LVCMOS | 3.3V |
| T200F-050.0M | Connor Winfield | T200 | TCXO | 50 MHz | LVCMOS | 3.3V |
| DOT050V-010.0M | Connor Winfield | DOT050V | VCTCXO | 10 MHz | LVCMOS | 3.3V |
| OH100-50503CF-010.0M | Connor Winfield | OH100 | OCXO | 10 MHz | CMOS | 3.3V |
| OH100-61003CV-010.0M | Connor Winfield | OH100 | VCOCXO | 10 MHz | CMOS | 3.3V |
| OH300-61003CF-050.0M | Connor Winfield | OH300 | OCXO | 50 MHz | CMOS | 3.3V |
| DGOF5S3-020.0M | Connor Winfield | DGOF | OCXO | 20 MHz | HCMOS, TTL | 5V |
| OX200-SC-010.0M | Connor Winfield | OX200-SC | VCOCXO | 10 MHz | LVCMOS | 12V |
| OD100LP-61005CV-010.0M | Connor Winfield | OD100LP | VCOCXO | 10 MHz | CMOS | 5V |
| OD100LP-61012SV-010.0M | Connor Winfield | OD100LP | VCOCXO | 10 MHz | Sine Wave | 12V |
| CWX823-025.0M | Connor Winfield | CWX823 | XO (Standard) | 25 MHz | LVCMOS | 3.3V |
| CWX823-032.768M | Connor Winfield | CWX823 | XO (Standard) | 32.768 MHz | LVCMOS | 3.3V |
| CWX813-033.0M | Connor Winfield | CWX813 | XO (Standard) | 33 MHz | LVCMOS | 3.3V |
| CWX813-060.0M | Connor Winfield | CWX813 | XO (Standard) | 60 MHz | LVCMOS | 3.3V |
| CWX813-001.8432M | Connor Winfield | CWX813 | XO (Standard) | 1.8432 MHz | LVCMOS | 3.3V |
| CWX813-004.0M | Connor Winfield | CWX813 | XO (Standard) | 4 MHz | LVCMOS | 3.3V |
| CWX813-016.384M | Connor Winfield | CWX813 | XO (Standard) | 16.384 MHz | LVCMOS | 3.3V |
| CWX813-019.44M | Connor Winfield | CWX813 | XO (Standard) | 19.44 MHz | LVCMOS | 3.3V |
| HSM613-024.576M | Connor Winfield | HSM6 | XO (Standard) | 24.576 MHz | HCMOS | 3.3V |
| HSM613-125.0M | Connor Winfield | HSM6 | XO (Standard) | 125 MHz | HCMOS | 3.3V |
| CWX813-029.4912M | Connor Winfield | CWX813 | XO (Standard) | 29.4912 MHz | LVCMOS | 3.3V |
| CWX813-066.6666M | Connor Winfield | CWX813 | XO (Standard) | 66.6666 MHz | LVCMOS | 3.3V |
| CWX823-156.25M | Connor Winfield | CWX823 | XO (Standard) | 156.25 MHz | LVCMOS | 3.3V |
| VKB61B2-010.0M | Connor Winfield | VKB | VCXO | 10 MHz | LVCMOS | 3.3V |
| B31-040.0M | Connor Winfield | B31 | TCXO | 40 MHz | Clipped Sine Wave | 3.3V |
