About ECS Inc .
ECS公司成立于1980年,总部位于美国堪萨斯州的Lenexa。43年来一直是频率控制和电源管理行业的行业领导者。ECS Inc. International以提供最新的新兴技术而闻名,产品范围广泛,包括晶体、振荡器、谐振器、石英和SAW滤波器、功率电感器以及最近的实时时钟。所有这些产品都非常适合汽车、医疗和多种无线/可穿戴应用。
ECS Inc. 已经开展国际业务超过40年,是全球公认的创新频率控制、同步、连接和磁力解决方案的开发商和制造商。四十多年来,ECS Inc.一直致力于可靠和创新的计时解决方案。
ECS Inc .凭借高度可靠和创新的无源元件,如晶体振荡器、SMD晶体、功率电感器、实时时钟和其他计时解决方案,满足了日益增长的全球需求。全球供应链网络以及在主要市场的关键设计和支持中心使ECS Inc .成为频率控制解决方案的主要供应商之一。
ECS Inc .已被多家世界级研究公司和电子设备设计师认定为无源元件行业的全球十大公司之一。截至今天,ECS Inc .已经向150多个国家的客户交付了超过34亿个被动计时和磁性解决方案。除了推动技术发展的产品,ECS Inc .在韩国、日本、中国、新加坡和美国拥有超过18个地点的全球工程和销售支持系统。
Founded in 1980 and headquartered in Lenexa, Kansas, USA, ECS Inc. International has been an industry leader in the frequency control and power management industry for 43 years. ECS Inc. International has built a reputation for providing the latest in emerging technologies with a broad range of products ranging from crystals, oscillators, resonator, quartz and SAW filters, power inductors, and most recently, real time clocks. All of these products are ideally suited for automotive, medical, and multiple wireless/wearable applications.
ECS Inc. have been conducting international business for more than 40 years and are a globally recognized developer and manufacturer of innovative frequency control, synchronization, connectivity and magnetic power solutions.For more than forty years, ECS Inc. has committed to reliable and innovative timing solutions.
ECS Inc. has met growing global demand with highly reliable and innovative passive components such as crystal oscillators, SMD crystals, power inductors, real time clocks and other timing solutions. The global supply chain network along with locations in key design and support centers in major markets allows ECS Inc. to remain as one of the primary providers of frequency control solutions.
ECS Inc. has been recognized by several world class research firms and electronic device designers as one of the top ten global companies in the passive component industry.
ECS原厂编码 | 型号 | 频率 | 频率偏差 | 负载电容 | 工作温度 | 尺寸 |
ECS-100-18-18-TR | CSM-12 | 10MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-100-S-18-TR | CSM-12 | 10MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-110.5-18-18-TR | CSM-12 | 11.0592MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-110.5-20-18-TR | CSM-12 | 11.0592MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-110.5-S-18-TR | CSM-12 | 11.0592MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-112.896-18-18-TR | CSM-12 | 11.2896MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-120-18-18-TR | CSM-12 | 12MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-120-S-18-TR | CSM-12 | 12MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-122.8-18-18-TR | CSM-12 | 12.288MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-143-20-18-TR | CSM-12 | 14.31818MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-143-S-18-TR | CSM-12 | 14.31818MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-147.4-18-18-TR | CSM-12 | 14.7456MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-153.6-18-18-TR | CSM-12 | 15.36MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-160-18-18-TR | CSM-12 | 16MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-160-S-18-TR | CSM-12 | 16MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-166.66-18-18-TR | CSM-12 | 16.666MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-184-18-18-TR | CSM-12 | 18.432MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-184-S-18-TR | CSM-12 | 18.432MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-196.6-S-18-TR | CSM-12 | 19.6608MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-200-18-18-TR | CSM-12 | 20MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-200-20-18-TR | CSM-12 | 20MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-200-S-18-TR | CSM-12 | 20MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-204.8-18-18-TR | CSM-12 | 20.48MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-221-18-18-TR | CSM-12 | 22.1184MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-240-16-18-TR | CSM-12 | 24MHz | ±30ppm | 16pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-240-18-18-TR | CSM-12 | 24MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-240-20-18-TR | CSM-12 | 24MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-245.7-18-18-TR | CSM-12 | 24.576MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-250-18-18-TR | CSM-12 | 25MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-35-17-18-TR | CSM-12 | 3.579545MHz | ±30ppm | 17pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-35-18-18-TR | CSM-12 | 3.579545MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-36-18-18-TR | CSM-12 | 3.6864MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-36-20-18-TR | CSM-12 | 3.6864MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-36-S-18-TR | CSM-12 | 3.6864MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-40-18-18-TR | CSM-12 | 4MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-40-20-18-TR | CSM-12 | 4MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-40-S-18-TR | CSM-12 | 4MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-41-18-18-TR | CSM-12 | 4.096MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-49-18-18-TR | CSM-12 | 4.9152MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-49-20-18-TR | CSM-12 | 4.9152MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-49-S-18-TR | CSM-12 | 4.9152MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-50-18-18-TR | CSM-12 | 5MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-60-18-18-TR | CSM-12 | 6MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-61-18-18-TR | CSM-12 | 6.144MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-61-32-18-TR | CSM-12 | 6.144MHz | ±30ppm | 32pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-73-18-18-TR | CSM-12 | 7.3728MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-73-20-18 | CSM-12 | 7.3728MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.465 L x 0.217 W (11.80mm x 5.50mm) |
ECS-73-S-18-TR | CSM-12 | 7.3728MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-80-18-18-TR | CSM-12 | 8MHz | ±30ppm | 18pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-80-20-18-TR | CSM-12 | 8MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-80-S-18-TR | CSM-12 | 8MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-98.3-20-18-TR | CSM-12 | 9.8304MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-98.3-S-18-TR | CSM-12 | 9.8304MHz | ±30ppm | Series | -40°C ~ 85°C | 0.465 L x 0.220 W (11.80mm x 5.50mm) |
ECS-120-20-3X-EN-TR | CSM-3X | 12MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-120-20-3X-TR | CSM-3X | 12MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-122.8-20-3X-TR | CSM-3X | 12.288MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-130-20-3X-EN-TR | CSM-3X | 13MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-130-20-3X-TR | CSM-3X | 13MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-135.6-20-3X-EN-TR | CSM-3X | 13.56MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-135.6-20-3X-TR | CSM-3X | 13.56MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-143-20-3X-EN-TR | CSM-3X | 14.31818MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-143-20-3X-TR | CSM-3X | 14.31818MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-147.4-20-3X-EN-TR | CSM-3X | 14.7456MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-147.4-20-3X-TR | CSM-3X | 14.7456MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-160-20-3X-EN-TR | CSM-3X | 16MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-160-20-3X-TR | CSM-3X | 16MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-184-20-3X-EN-TR | CSM-3X | 18.432MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-184-20-3X-TR | CSM-3X | 18.432MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-196.6-20-3X-EN-TR | CSM-3X | 19.6608MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-196.6-20-3X-TR | CSM-3X | 19.6608MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-200-20-3X-EN-TR | CSM-3X | 20MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-200-20-3X-TR | CSM-3X | 20MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-200-CDX-0914 | CSM-3X | 20MHz | ±10ppm | 10pF | -60°C ~ 105°C | 0.299 L x 0.161 W (7.60mm x 4.10mm) |
ECS-245.7-20-3X-EN-TR | CSM-3X | 24.576MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-245.7-20-3X-TR | CSM-3X | 24.576MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-250-20-3X-EN-TR | CSM-3X | 25MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-250-20-3X-TR | CSM-3X | 25MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-270-20-3X-EN-TR | CSM-3X | 27MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-270-20-3X-TR | CSM-3X | 27MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-286.3-20-3X-EN-TR | CSM-3X | 28.63636MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-286.3-20-3X-TR | CSM-3X | 28.63636MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-300-20-3X-EN-TR | CSM-3X | 30MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-300-20-3X-TR | CSM-3X | 30MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-330-20-3X-EN-TR | CSM-3X | 33MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-330-20-3X-TR | CSM-3X | 33MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-400-20-3X-EN-TR | CSM-3X | 40MHz | ±30ppm | 20pF | -40°C ~ 85°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-400-20-3X-TR | CSM-3X | 40MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.276 L x 0.161 W (7.00mm x 4.10mm) |
ECS-100-20-28A-TR | CSM-4A | 10MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.492 L x 0.191 W (12.50mm x 4.85mm) |
ECS-100-S-28A-TR | CSM-4A | 10MHz | ±30ppm | Series | -10°C ~ 70°C | 0.492 L x 0.191 W (12.50mm x 4.85mm) |
ECS-110.5-20-28A-TR | CSM-4A | 11.0592MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.492 L x 0.191 W (12.50mm x 4.85mm) |
ECS-110.5-S-28A-TR | CSM-4A | 11.0592MHz | ±30ppm | Series | -10°C ~ 70°C | 0.492 L x 0.191 W (12.50mm x 4.85mm) |
ECS-120-18-28A-TR | CSM-4A | 12MHz | ±30ppm | 18pF | -10°C ~ 70°C | 0.492 L x 0.191 W (12.50mm x 4.85mm) |
ECS-120-32-28A-TR | CSM-4A | 12MHz | ±30ppm | 32pF | -10°C ~ 70°C | 0.492 L x 0.191 W (12.50mm x 4.85mm) |
ECS-120-S-28A-TR | CSM-4A | 12MHz | ±30ppm | Series | -10°C ~ 70°C | 0.492 L x 0.191 W (12.50mm x 4.85mm) |
ECS-122.8-20-28A-TR | CSM-4A | 12.288MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.492 L x 0.191 W (12.50mm x 4.85mm) |
ECS-143-20-28A-TR | CSM-4A | 14.31818MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.492 L x 0.191 W (12.50mm x 4.85mm) |
ECS-143-S-28A-TR | CSM-4A | 14.31818MHz | ±30ppm | Series | -10°C ~ 70°C | 0.492 L x 0.191 W (12.50mm x 4.85mm) |
ECS-147.4-20-28A-TR | CSM-4A | 14.7456MHz | ±30ppm | 20pF | -10°C ~ 70°C | 0.492 L x 0.191 W (12.50mm x 4.85mm) |
ECS-147.4-S-28A-TR | CSM-4A | 14.7456MHz | ±30ppm | Series | -10°C ~ 70°C | 0.492 L x 0.191 W (12.50mm x 4.85mm) |
