LORA模块低抖动专用晶振530FC125M000DG/125MHz/XO/7050mm/2.5V/SMD-6
Silicon晶振Si530 XO利用天空工作解决方案的先进DSPLL®电路提供一个高频低抖动时钟。Si530可提供从10到945MHz的任意速率输出频率,并选择频率到1400MHz。与传统的XO不同,每个输出频率都需要一个不同的晶体,石英晶体振荡器Si530使用一个固定的晶体来提供一个大范围的输出频率。这种基于集成电路的方法允许晶体谐振器提供特殊的频率稳定性和可靠性。此外,DSPLL时钟合成提供了优越的电源噪声抑制,简化了在通信系统中通常发现的噪声环境中产生低抖动时钟的任务。有源晶振Si530 IC的XO可在工厂中进行配置,可用于各种用户规格,包括频率、电源电压、输出格式和温度稳定性。特定的配置在装运时被工厂编程,从而消除了与定制振荡器相关的长交货时间。LORA模块低抖动专用晶振530FC125M000DG/125MHz/XO/7050mm/2.5V/SMD-6
原厂代码 | 贴片晶振厂家 | 型号 | 频率 | 电压 | 频率稳定度 | 包装/封装 |
530FB125M000DG | Silicon晶振 | Si530 | 125MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
530BB125M000DG | Silicon晶振 | Si530 | 125MHz | 3.3V | ±20ppm | 6-SMD, No Lead |
530FB200M000DG | Silicon晶振 | Si530 | 200MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
530BC156M250DG | Silicon晶振 | Si530 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BA125M000DG | Silicon晶振 | Si530 | 125MHz | 3.3V | ±50ppm | 6-SMD, No Lead |
530BB100M000DG | Silicon晶振 | Si530 | 100MHz | 3.3V | ±20ppm | 6-SMD, No Lead |
530FC156M250DG | Silicon晶振 | Si530 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FA156M250DG | Silicon晶振 | Si530 | 156.25MHz | 2.5V | ±50ppm | 6-SMD, No Lead |
530FC125M000DG | Silicon晶振 | Si530 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530AC622M080DG | Silicon晶振 | Si530 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530AC125M000DG | Silicon晶振 | Si530 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530AC200M000DG | Silicon晶振 | Si530 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC200M000DG | Silicon晶振 | Si530 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530FC200M000DG | Silicon晶振 | Si530 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530AC156M250DG | Silicon晶振 | Si530 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530AC155M520DG | Silicon晶振 | Si530 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC148M500DG | Silicon晶振 | Si530 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530AC106M250DG | Silicon晶振 | Si530 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC106M250DG | Silicon晶振 | Si530 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC106M250DG | Silicon晶振 | Si530 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530BC106M250DG | Silicon晶振 | Si530 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC155M520DG | Silicon晶振 | Si530 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530EC187M500DG | Silicon晶振 | Si530 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530AC000110DG | Silicon晶振 | Si530 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530AC148M500DG | Silicon晶振 | Si530 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC000110DG | Silicon晶振 | Si530 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC000110DG | Silicon晶振 | Si530 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530BC155M520DG | Silicon晶振 | Si530 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC156M250DG | 贴片晶振 | Si530 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530AC187M500DG | Silicon晶振 | Si530 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC187M500DG | Silicon晶振 | Si530 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530FC187M500DG | Silicon晶振 | Si530 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530EC148M500DG | Silicon晶振 | Si530 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530EC200M000DG | Silicon晶振 | Si530 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC155M520DG | Silicon晶振 | Si530 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530BC000110DG | Silicon晶振 | Si530 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530FC148M500DG | Silicon晶振 | Si530 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530EC312M500DG | Silicon晶振 | Si530 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530BC250M000DG | Silicon晶振 | Si530 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC311M040DG | Silicon晶振 | Si530 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC311M040DG | Silicon晶振 | Si530 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC622M080DG | Silicon晶振 | Si530 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530BC311M040DG | Silicon晶振 | Si530 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC622M080DG | Silicon晶振 | Si530 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530BC622M080DG | Silicon晶振 | Si530 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530AC311M040DG | Silicon晶振 | Si530 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530FC312M500DG | Silicon晶振 | Si530 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530AC312M500DG | Silicon晶振 | Si530 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC250M000DG | Silicon晶振 | Si530 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530AC250M000DG | Silicon晶振 | Si530 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530FC250M000DG | Silicon晶振 | Si530 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530BC312M500DG | Silicon晶振 | Si530 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530FC50M0000DG | Silicon晶振 | Si530 | 50MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530AA156M250DG | Silicon晶振 | Si530 | 156.25MHz | 3.3V | ±50ppm | 6-SMD, No Lead |
530FB100M000DG | Silicon晶振 | Si530 | 100MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
530BC125M000DG | Silicon晶振 | Si530 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC125M000DG | Silicon晶振 | Si530 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530CA28M6000DG | Silicon晶振 | Si530 | 28.6MHz | 3.3V | ±50ppm | 6-SMD, No Lead |
530AC125M000DGR | Silicon晶振 | Si530 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC125M000DGR | Silicon晶振 | Si530 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC125M000DGR | Silicon晶振 | Si530 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530AC106M250DGR | Silicon晶振 | Si530 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC106M250DGR | Silicon晶振 | Si530 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC106M250DGR | Silicon晶振 | Si530 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC106M250DGR | Silicon晶振 | Si530 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530BC25M0000DGR | Silicon晶振 | Si530 | 25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530RB150M000DG | Silicon晶振 | Si530 | 150MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
530RB200M000DG | Silicon晶振 | Si530 | 200MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
530BC100M000DG | Silicon晶振 | Si530 | 100MHz | 3.3V | ±20ppm | 6-SMD, No Lead |
530AC155M520DGR | Silicon晶振 | Si530 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530AC156M250DGR | Silicon晶振 | Si530 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC155M520DGR | Silicon晶振 | Si530 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC156M250DGR | Silicon晶振 | Si530 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC155M520DGR | Silicon晶振 | Si530 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530EC156M250DGR | Silicon晶振 | Si530 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC155M520DGR | Silicon晶振 | Si530 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC156M250DGR | Silicon晶振 | Si530 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530AC187M500DGR | Silicon晶振 | Si530 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC187M500DGR | Silicon晶振 | Si530 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC187M500DGR | Silicon晶振 | Si530 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC187M500DGR | Silicon晶振 | Si530 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530AC000110DGR | 进口晶振 | Si530 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530AC148M500DGR | Silicon晶振 | Si530 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530AC200M000DGR | Silicon晶振 | Si530 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC000110DGR | Silicon晶振 | Si530 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC148M500DGR | Silicon晶振 | Si530 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC200M000DGR | Silicon晶振 | Si530 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC000110DGR | Silicon晶振 | Si530 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530EC148M500DGR | Silicon晶振 | Si530 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530EC200M000DGR | Silicon晶振 | Si530 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC000110DGR | Silicon晶振 | Si530 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC148M500DGR | Silicon晶振 | Si530 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530BC130M250DG | Silicon晶振 | Si530 | 130.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC154M000DG | Silicon晶振 | Si530 | 154MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530AC312M500DGR | Silicon晶振 | Si530 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC312M500DGR | Silicon晶振 | Si530 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC312M500DGR | Silicon晶振 | Si530 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC312M500DGR | Silicon晶振 | Si530 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530AC250M000DGR | Silicon晶振 | Si530 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530AC311M040DGR | Silicon晶振 | Si530 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530AC622M080DGR | Silicon晶振 | Si530 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC250M000DGR | Silicon晶振 | Si530 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC311M040DGR | Silicon晶振 | Si530 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530BC622M080DGR | Silicon晶振 | Si530 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
530EC250M000DGR | Silicon晶振 | Si530 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530EC311M040DGR | Silicon晶振 | Si530 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530EC622M080DGR | Silicon晶振 | Si530 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC250M000DGR | Silicon晶振 | Si530 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC311M040DGR | Silicon晶振 | Si530 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530FC622M080DGR | Silicon晶振 | Si530 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
530CA40M0000BG | Silicon晶振 | Si530 | 40MHz | 3.3V | ±50ppm | 6-SMD, No Lead |
Si530晶振特点:
可与任意速率输出频率从10MHz到945MHz和选择频率1.4GHz
第三代DSPLL®具有优越的抖动性能
比基于saw的振荡器好3倍的频率稳定性
内部固定晶体频率确保高可靠性和低老化
可用CMOS,LVPECL,LVDS,和CML输出差分晶振
3.3V,2.5V,和1.8V供应选项
工业标准7.0x5.0mm毫米包和针形
无铅/RoHS兼容
应用于:超声波SONET/SDH,网络,SD/高清视频,测试和测量,时钟和数据恢复,FPGA/ASIC时钟生成
